The work establishes a number of features regarding the mechanics of freezing wet quartz sands when manufacturing products of limited sizes from them. Products of limited sizes from frozen sand in foundry production are casting models used for manufacturing volumetrically closed and detachable casting molds using the SMS-process method, frozen casting molds and rods, etc. The work used quarry quartz sand of the 1K2O202 brand and tap water. The mass was measured on a VTA-60/6-73-AL-2 scale with an accuracy of ±1 g. The temperature was measured with an alcohol thermometer of the TTZ type and a chromel-copel thermocouple complete with an electronic device of the STC-1000 brand with an accuracy of ±1 С with video recording of temperature changes over time with an interval of 1 s. Drying of sand was carried out in a microwave oven with a magnetron power of 900 W and a microwave radiation frequency of 2.45 MHz. Freezing of wet sand was carried out in a refrigeration chamber with a capacity of 17 kg/day at a temperature of -20 °C. According to the results of the research, it was found that flat products with a thickness of 10 mm, regardless of the water content (up to 12.5% above), under conditions of unidirectional heat removal, cool to 0 °C faster than dry quartz sand. Freezing of wet sand under conditions of multidirectional heat removal from it leads to a significant migration of water in the sand in the direction of gravity, i.e. from the solidification front of wet sand to a surface with a higher temperature, which is in the direction of movement of unfrozen water. Increasing the initial temperature of wet sand contributes to an increase in the rate of its cooling to 0 °C and the time of solidification of water, but increases the total time of solidification of wet sand.
